4U GPU A+ Server AS -4125GS-TNRT2 (AS -4125GS-TNRT2)

Key Features

Flexible GPU support: active & passive GPUsDual Root Configuration with PCIe Switch for up to 10 double width, full length GPUs8 Hot-Swap Heavy Duty Fans with Optimal Fan Speed Control
Dual-Socket, AMD EPYC™ 9004/9005 Series Processors up to 360W TDP
Supports up to 24 DIMM Slots, 6000 MT/s 6TB DDR5 memory(Please check System Memory Section for detail)
AIOM / OCP 3.0 Support
Total of 8 Hot-swap 2.5" NVMe drive bays1 M.2 Slot
Total of 4x 2000W Redundant (2 + 2) Titanium Level power supplies(Power supply full redundancy based on configuration and application load)

€0,00

(Excl. btw)

€0,00

(Incl. btw)

Verzending binnen 3-5 werkdagen

Via uw winkelmand kunt u ook direct een offerte aanvragen.

Beschikbaarheid opvragen

Minimaal 1 jaar Carry-in-garantie voor servers

Wij assembleren en testen uw bestelling zorgvuldig

Supermicro Product ID: AS-4125GS-TNRT2

Hulp Nodig? Contacteer onze experts

Beschikbaar van maandag tot vrijdag, 09:00 - 17:30 uur

+31(0)85-3018585

Begin Chat

Specificaties

Product SKUs
A+ Server AS -4125GS-TNRT2

Motherboard
Super H13DSG-O-CPU

Processor
CPU	Dual Socket SP5 AMD EPYC™ 9004 Series Processors
Core Count	Up to 128C/256T
Note	Supports up to 400W TDP CPUs (Air Cooled)

GPU
Max GPU Count	Up to 10 double-width GPU(s)
Supported GPU	NVIDIA PCIe: H100 NVL, H100, L40, RTX A6000, RTX A5000, RTX A4000, RTX 6000 Ada Generation, L40S, A40, A30, A100 AMD PCIe: Instinct MI210 View GPU Options
CPU-GPU Interconnect	PCIe 5.0 x16 Switch Dual-Root
GPU-GPU Interconnect	NVIDIA® NVLink® Bridge (optional), AMD Infinity Fabric™ Link (optional)

System Memory
Memory	Slot Count: 24 DIMM slots Max Memory (1DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM/LRDIMM View Memory Options
Memory Voltage	1.1V

On-Board Devices
SATA	SATA (6Gbps)
Chipset	AMD SP5
Network Connectivity	2 RJ45 10GbE View AIOM Options View AOC Options
NVMe	View NVMe Options

Input / Output
LAN	1 RJ45 1 GbE Dedicated IPMI LAN port(s) 2 RJ45 10 GBASE-T LAN port(s)
USB	2 port(s) (rear)
Video	1 VGA port(s)
Serial	1 COM port(s) (Rear)

System BIOS
BIOS Type	AMI 32MB SPI Flash EEPROM

Management
Software	SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New!
Power configurations	Power-on mode for AC power recovery ACPI Power Management

Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown

PC Health Monitoring
CPU	Monitors for CPU Cores, Chipset Voltages, Memory 7 +1 Phase-switching voltage regulator
FAN	Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
